S110-8LP2ST technical indicators
| Project | Describe |
|---|---|
| Dimensions (W x D x H, excluding packaging) [mm] | Basic dimensions (depth is the distance excluding the protruding structural parts of the front and rear panels): 210.0mm×130.0mm×35mm
Maximum size (depth is the maximum distance from the protruding port on the front panel to the protruding structure on the rear panel): 210.0mm×131.7mm×36.5mm |
| Dimensions (W x D x H, including packaging) [mm] | 280.0mm×270.0mm×55.0mm |
| Chassis height [U] | 0.8U |
| Chassis material | PC+ABS |
| Weight (excluding packaging materials) [kg] | 0.61kg |
| Weight (including packaging) [kg] | 0.85kg |
| Typical power consumption [W] | 8W |
| Typical heat dissipation value [BTU/hour] | 27.30BTU/hour |
| Maximum power consumption [W] | Without PoE: 8.4W
PoE full load: 70W (PoE: 54W) |
| Maximum heat dissipation value [BTU/hour] | Without PoE: 28.66
PoE full load: 238.85 |
| Static power consumption [W] | 3W |
| MTBF [years] | 85.44years |
| MTTR [hours] | 2hours |
| Availability | > 0.99999 |
| Noise at room temperature (sound power) [dB(A)] | No fan, silent, <30 |
| Noise at normal temperature (sound pressure) [dB(A)] | No fan, silent, <20 |
| Number of card slots | 0 |
| Number of power supply slots | 0 |
| Number of fan modules | 0 |
| Switching capacity | If you need this specification, please check the product brochure or contact the product salesperson to obtain it. |
| Packet forwarding rate | If you need this specification, please check the product brochure or contact the product salesperson to obtain it. |
| Operating mode | Standard mode, port isolation, flow control off |
| Number of MAC addresses | 2K |
| Power redundancy | not support |
| Long-term working environment temperature [°C] | 0°C～+40°C (0m～1800m above sea level) |
| Operating environment temperature change limit [°C] | 1800 m to 5000 m: The maximum temperature specification decreases by 1°C every time the altitude increases by 220 m. |
| Storage temperature [°C] | -40°C～+70°C |
| Long-term working environment relative humidity [RH] | 5%RH～95%RH, non-condensing |
| Long-term working altitude [m] | 0m～5000m |
| Storage altitude [m] | 0m～5000m |
| Power supply type | Power Adapter |
| Rated input voltage [V] | Power adapter input: 100V AC ~ 240V AC; 50/60Hz
Power adapter output: 54V DC |
| Input voltage range[V] | Power adapter input: 90V AC ~ 264V AC; 47Hz ~ 63Hz |
| Maximum input current [A] | 1.17A |
| Memory | – |
| Flash | – |
| Console Interface Type | not support |
| Eth management network port type | not support |
| USB interface | not support |
| Real-time Clock (RTC) | not support |
| RPS Input | not support |
| Business port lightning protection [kV] | Common mode ±4kV |
| Power port lightning protection [kV] | Differential mode ±2kV, common mode ±4kV |
| Triple protection (dustproof/waterproof) | IP20 |
| Fan Type | Fanless |
| Cooling method | Natural cooling |
| Airflow direction | – |
| PoE Function | support |
| certified product | Support EMC certification
Support safety certification Support production certification |
