FortiGuard Bundles
FortiGuard Labs delivers a number of security intelligence services to augment the FortiGate firewall platform. You can easily optimize the protection capabilities of your Fortinet FortiGate 401E with one of these FortiGuard Bundles.
| 360 Protection Bundle | Enterprise Protection Bundle | Unified Threat Protection Bundle | Advanced Threat Protection Bundle | |
|---|---|---|---|---|
| FortiCare | ASE1 | 24×7 | 24×7 | 24×7 |
| FortiGuard App Control Service | √ | √ | √ | √ |
| FortiGuard IPS Service | √ | √ | √ | √ |
| FortiGuard Advanced Malware Protection (AMP) (Antivirus, Mobile Malware, Botnet, CDR, Virus Outbreak Protection & FortiSandbox Cloud Service3) |
√ | √ | √ | √ |
| FortiGuard Web & Video2 Filtering Service | √ | √ | √ | |
| FortiGuard Antispam Service | √ | √ | √ | |
| FortiGuard Security Rating Service | √ | √ | ||
| FortiGuard IoT Detection Service | √ | √ | ||
| FortiGuard Industrial Service | √ | √ | ||
| FortiConverter Service | √ | √ | ||
| SD-WAN Orchestrator Entitlement | √ | |||
| SD-WAN Cloud Assisted Monitoring | √ | |||
| SD-WAN Overlay Controller VPN Service | √ | |||
| Fortinet SOCaaS | √ | |||
| FortiAnalyzer Cloud3 | √ | |||
| FortiManager Cloud3 | √ |
Data Sheet
| General | |
|---|---|
| Manufacturer | Fortinet |
| GTIN-/EAN-Code | 842382125342 |
| In assortment since | 12.08.2019 |
| Application Area | |
| Typical application area | corporate datacenters an distributed enterprise |
| Network Size Class | 250-1,000 users/devices |
| Interfaces | |
| 1-GbE-RJ45 Ports | 18x (including 2 for MGMT and HA) |
| 1-GbE-SFP Ports | 16x |
| Data Storage | |
| Storage Capacity | 240 GB (2x 240 GB SSD) |
| Network | |
| Packets per second (Mpps) | 36 |
| Concurrent sessions | 4,000,000 |
| Concurrent Sessions (SSL) | 300,000 |
| New Sessions per second | 450,000 |
| Network latency | 3µs |
| Maximum supported switches (external) | 48 |
| Firewall | |
| Firewall Throughput | 32.0 Gbps |
| Firewall Throughput (IMIX) | 24.0 Gbps |
| Threat Protection Throughput | 5.0 Gbps |
| IPS Throughput | 7.8 Gbps |
| Application Control Throughput | 12.0 Gbps |
| SSL Inspection Throughput | 4.8 Gbps |
| VPN | |
| IPSec VPN Throughput | 20.0 Gbps |
| SSL VPN throughput | 4.5 Gbps |
| Site-2-Site IPSec VPN Tunnels | 2,000 |
| Client VPN Tunnels | 55,000 (50.000 IPSec (max.), 5.000 concurrent SSL VPN users) |
| SSL VPN Client Licenses included | Unlimited |
| IPSec VPN Client Licenses included | Unlimited |
| Wireless | |
| Maximum supported Access Points | 512 (256 in FortiAP Tunnel Mode) |
| Dimensions | |
| Form Factor | 19-inch rack mount (1U) |
| Dimensions (WxDxH) | 432mm x 380mm x 44.5mm |
| Weight | 7.90 kg |
| Power Supply | |
| Power Supply | Internal Power Supply Unit, Hot Swappable |
| Number of Power Supply Units included / maximum | 1 / 2 |
