CBL-JNP-PWR-DSUB DC power cable. DSUB 3W3 connector (3-pin: -48VDC input, return, ground). Rated 40A at -48VDC nominal (-48V to -60VDC range). 4m length. 8 AWG (8.4 mm²) conductors, 90°C rated. Color code: Blue (- input), Black (return +), Green/Yellow (ground). Required for EX4400 DC PSU connections in slot 0/1. Field termination at source end.
Connect to -48VDC distribution before chassis grounding. Maintain polarity. Copper conductors only.
| Electrical Characteristics | |
|---|---|
| Voltage Range | -48VDC to -60VDC |
| Current Rating | 40A |
| Power Support | Up to 550W DC PSUs |
| Cable & Physical | |
| Length | 4m (13.1 ft) |
| Wire Gauge | 8 AWG (8.4 mm²), 90°C |
| Conductors | 3x (Blue -, Black +, Green/Yellow Ground) |
| Connector | D-Sub 3W3 (PSU end) |
| Compatibility | |
| Platforms | EX4400 Series DC PSUs (JPSU-550-C-DC-*) |
