CloudEngine 5800 series switches deliver high gigabit access, enabling enterprises and carriers to build cloud-oriented data center networks. Featuring 40 GE uplink ports and flexible airflow capabilities, the switches are capable of forming a 9-member stack system and are well-suited for either the aggregation or the access layer. Coupled with CloudEngine 16800 or 12800 series switches, CloudEngine 5800 enables enterprises to build networks that are scalable, simplified, open — and secure.
CE5880-48T6Q-EI Specifications |
|
| Model | CE5880-48T6Q-EI |
| Brand | Huawei |
| Series | CE5800 |
| Ports | 48 x 10GE SFP+ |
| QoS | Supported |
| Switching Capacity | 2.56 Tbps |
| Forwarding Performance | 720 Mpps |
| Redundant Power Supply | Supported |
| Dimensions (H x W x D) | 44.0 mm x 442.0 mm x 420.0 mm |
| Operating Temperature | 0°C to 40°C (32°F to 104°F) |
| Storage Temperature | -40°C to +70°C (-40°F to +158°F) |
| Input Voltage | 100V-240V AC, 50/60 Hz |
| Fan | Hot-swappable, variable speed |
| MAC Address Table | 32K |
| Maximum VLANs | 4K |
| Spanning Tree Protocols | STP, RSTP, MSTP |
| Jumbo Frame | Supported, 9KB |
| IPv6 | Supported |
| Security Features | 802.1X, ACL, SSH, RADIUS |
| Management | QinQ, SNMP, RMON, Web-based GUI |
