Product Brief
The Cisco FPR4K-NM-2X40G-F(Picture 1 ) Firepower 2-port 40G SR FTW Network Module is a high-performance expansion module for Cisco Firepower 4100 Series appliances. It provides 40-Gigabit Ethernet connectivity with Short Range (SR) optics, delivering ultra-fast data transfer for high-speed network environments. Additionally, this module features hardware bypass functionality to ensure continuous traffic flow in case of failure, minimizing downtime.
Picture 1 FPR4K-NM-2X40G-F
Hardware Specifications
| Specification | Details |
|---|---|
| Ports | 2 x 40GBASE-SR4 |
| Interface Type | QSFP+ (Quad Small Form-factor Pluggable) |
| Data Rate | 40 Gbps (Gigabits per second) |
| Connector Type | Optical (fiber) |
| Bypass Capability | Yes (Hardware Bypass on Ports 1 and 2) |
| Cable Type | OM3 multimode fiber |
| Maximum Cable Distance | 100 meters (OM3) |
| Form Factor | Single-wide module |
| Module Type | 40-Gigabit Ethernet |
| LED Indicators | Link activity (Green), Network failure (Amber), Bypass (Amber) |
| Power Consumption | 15W (typical) |
| Compatibility | Cisco Firepower 4100 Series Chassis |
| Compliance | NEBS (Network Equipment Building Standards) certified |
Use Cases
- Data centers with high-speed interconnects.
- Enterprise networks handling large traffic volumes.
- Telecommunications and cloud infrastructures where performance and uptime are critical.
