Cisco Nexus 93180YC-EX

Name: Cisco Nexus 93180YC-EX
Brand: Cisco
SKU: N9K-C93180YC-EX
Price: 13500.00 USD
Availability: InStock
Rating: 5 (2 reviews)

Model (MPN)

N9K-C93180YC-EX

SKU

N9K-C93180YC-EX

Condition

New Retail

Certified Engineer Tested

Out of Stock

Key Specifications

Downlink Ports48 x 1/10/25-Gbps fiber ports

Uplink Ports6 x 40/100-Gbps QSFP28 ports

Management Ports2 ports: 1 RJ-45 and 1 SFP

USB Ports1

RS-232 Serial Ports1

Bandwidth3.6 Tbps

Your Price

Best Value

$13,500.00

List Price: $15,000.00Save 10%

Availability Out of Stock

Quantity

Need configuration help?

Our CCIE certified engineers can help you verify compatibility.

Secure Payment

VISA

Pay

WIRE

Fast Dispatch

Global logistics network aiming for same-day handover.

48hrs

Avg. Shipping

99%

On-Time

Guaranteed Quality

Every unit undergoes rigorous 38-point inspection test.

3Year

Warranty

0.1%

RMA Rate

Global Reach

Trusted by enterprise clients across 6 continents.

85+

Countries

20k+

Clients

Expert Support

Certified network engineers ready to assist with configuration.

24/7

Assistance

CCIE

Certified

Overview

The Cisco Nexus 93180YC-EX is a fixed 1-Rack-Unit (1RU) switch from the Cisco Nexus 9300-EX Series, part of the Nexus 9000 platform based on Cisco Cloud Scale technology. Designed for cost-effective cloud-scale deployments, it supports an increased number of endpoints and cloud services with modern system architecture delivering high performance for highly scalable data centers and growing enterprises. This switch offers 3.6 Terabits per second (Tbps) of bandwidth and over 2.6 billion packets per second (bpps) with latency of less than 1 microsecond.

Port Configuration and Migration Flexibility

The Nexus 93180YC-EX features 48 downlink ports configurable as 1-, 10-, or 25-Gbps fiber ports, providing deployment flexibility and investment protection. The 6 uplink QSFP28 ports support up to 40- and 100-Gbps, or combinations of 1-, 10-, 25-, 40-, 50-, and 100-Gbps connectivity for seamless migration from 100-Mbps, 1-Gbps, 10-Gbps to 25-Gbps server speeds and 10-/40-Gbps to 50-/100-Gbps aggregation. FC-FEC is enabled for 25Gbps, supporting up to 3m DAC connectivity. Refer to the Cisco Optics Matrix for updated support. With 2 units in stock at a special offer of $13,500 (save 10%), immediate dispatch is available. PDF Datasheet downloadable for full details.

Operational Modes

Cisco Nexus 9000 Series Switches, including the 93180YC-EX, support two modes: Cisco NX-OS Software for standard environments and ACI mode for automated, policy-based management with Cisco Application Centric Infrastructure (ACI).

Key Features and Benefits

Advanced Capabilities

Supports up to 16 Cisco Nexus 2000 Series Fabric Extenders. Comprehensive Layer 2/3 scalability for virtualized data centers and automated clouds. RoHS compliant. MTBF of 390,330 hours. Management ports: 2 (1 RJ-45, 1 SFP); USB and RS-232 serial ports. Airflow: port-side intake/exhaust. Acoustics: 48.5 dBA at 40% fan speed, up to 77.8 dBA at 100%.

Applications and Deployment

Ideal for web-scale fabrics, IP fabrics, storage networking. Enables large buffers, flexible scalability. With availability of 2 units and special pricing, deploy quickly in your data center infrastructure. Cisco provides extensive support including Quick Start, Accelerated Deployment, Migration Services, and 24/7 Product Support. Environmental sustainability details in CSR report, with compliance to WEEE, materials regulations.

For optics, software licensing (Essential/Advantage for ACI/NX-OS), and full ordering, consult the datasheet. Compatible power supplies, fans, cords, accessories listed therein.

Specifications

Ports and Interfaces
Downlink Ports	48 x 1/10/25-Gbps fiber ports
Uplink Ports	6 x 40/100-Gbps QSFP28 ports
Management Ports	2 ports: 1 RJ-45 and 1 SFP
USB Ports	1
RS-232 Serial Ports	1
Performance and Capacity
Bandwidth	3.6 Tbps
Packets per Second	Over 2.6 bpps
Latency	Less than 1 microsecond
System Buffer	40 MB
Maximum LPM Routes	896,000
Maximum IP Host Entries	896,000
Maximum MAC Addresses	256,000
Maximum Multicast Routes	32,000
IGMP Snooping Groups	Shipping: 8,000; Maximum: 32,000
Maximum Nexus 2000 FEX per Switch	16
Maximum ACL Entries	Per slice: 4000 ingress, 2000 egress; Total (2 slices): 8000 ingress, 4000 egress
Maximum VLANs	4096
VRF Instances	Shipping: 1,000; Maximum: 16,000
Maximum ECMP Paths	64
Maximum Port Channels	512
Maximum Links per Port Channel	32
Active SPAN Sessions	4
Maximum VLANs in RPVST	3,967
Maximum HSRP Groups	490
NAT Entries	1,023
Maximum MST Instances	64
Tetration Flow-Table Size	64,000
Number of Queues	8
Hardware Specifications
CPU	4 cores
System Memory	24 GB
SSD Drive	64 GB
Fans	4
Airflow	Port-side intake and exhaust
Physical Dimensions (H x W x D)	1.72 x 17.3 x 22.5 in. (4.4 x 43.9 x 57.1 cm)
Acoustics	48.5 dBA at 40% fan speed, 64.9 dBA at 70% fan speed, 77.8 dBA at 100% fan speed
RoHS Compliance	Yes
MTBF	390,330 hours
Minimum ACI Image	ACI-N9KDK9-11.3
Minimum NX-OS Image	NXOS-703I4.2
Power Specifications
Power Supplies (up to 2)	500W AC, 650W AC, 930W DC, or 1200W HVAC/HVDC
Typical Power (AC/DC)	210W
Maximum Power (AC/DC)	470W
BTU/hr	1604
Input Voltage (AC)	100 to 240V
Input Voltage (HVAC)	200 to 277V
Input Voltage (DC)	–48 to –60V
Input Voltage (HVDC)	–240 to –380V
Frequency (AC)	50 to 60 Hz
Environmental Properties
Operating Temperature	32 to 104°F (0 to 40°C)
Nonoperating Temperature	–40 to 158°F (–40 to 70°C)
Humidity	5 to 95% (noncondensing)
Altitude	0 to 13,123 ft (0 to 4000m)
Weight
Switch without PSUs/Fans	17.2 lb (7.8 kg)
500W AC PSU	2.42 lb (1.1 kg)
650W AC PSU	2.42 lb (1.1 kg)
930W DC PSU	2.42 lb (1.1 kg)
1200W HVDC/HVAC PSU	2.42 lb (1.1 kg)
Fan Tray (NXA-FAN-30CFM-F/B)	0.26 lb (0.12 kg)
Regulatory Compliance
Regulatory	CE Markings: 2004/108/EC and 2006/95/EC
Safety	NEBS; UL 60950-1 Second Edition; CAN/CSA-C22.2 No. 60950-1 Second Edition; EN 60950-1 Second Edition; IEC 60950-1 Second Edition; AS/NZS 60950-1; GB4943
EMC Emissions	47CFR Part 15 Class A; AS/NZS CISPR22 Class A; CISPR22 Class A; EN55022 Class A; ICES003 Class A; VCCI Class A; EN61000-3-2; EN61000-3-3; KN22 Class A; CNS13438 Class A
EMC Immunity	EN55024; CISPR24; EN300386; KN 61000-4 series
RoHS	RoHS-6 compliant (exceptions for leaded BGA balls and lead press-fit connectors)
Ordering Information - Base Part Numbers
N9K-C93180YC-EX	Nexus 9K Fixed with 48p 1/10G/25G SFP and 6p 40G/100G QSFP28
N9K-C93108TC-EX	Nexus 9K Fixed with 48p 10G BASE-T and 6p 40G/100G QSFP28
N9K-C93180LC-EX	Nexus 9K Fixed with up to 32p 40/50G QSFP+ or up to 18p 100G QSFP28
Ordering Information - Power Supplies
NXA-PAC-500W-PI	Nexus 9000 500W AC PS, Port-side Intake; Supported on Nexus 93180YC-EX and 93108TC-EX only
NXA-PAC-500W-PE	Nexus 9000 500W AC PS, Port-side Exhaust; Supported on Nexus 93180YC-EX and 93108TC-EX only
NXA-PDC-930W-PI	Nexus 9000 930W DC PS, Port-side Intake
NXA-PDC-930W-PE	Nexus 9000 930W DC PS, Port-side Exhaust
N9K-PUV-1200W	Nexus 9300 1200W Universal Power Supply, Bi-directional air flow and Supports HVAC/HVDC
Ordering Information - Fans
NXA-FAN-30CFM-F	Nexus Single Fan, 30CFM, port side exhaust airflow
NXA-FAN-30CFM-B	Nexus Single Fan, 30CFM, port side intake airflow
Ordering Information - Licenses
C1E1TN9300XF-3Y	ACI & NX-OS Subscription Essential package for 10/25/40G+ Nexus 9K Leaf, 3 Year Term
C1E1TN9300XF-5Y	ACI & NX-OS Subscription Essential package for 10/25/40G+ Nexus 9K Leaf, 5 Year Term
C1A1TN9300XF-3Y	ACI & NX-OS Subscription Advantage package for 10/25/40G+ Nexus 9K Leaf, 3 Year Term
C1A1TN9300XF-5Y	ACI & NX-OS Subscription Advantage package for 10/25/40G+ Nexus 9K Leaf, 5 Year Term
ACI-ES-XF	ACI Essential SW license for a 10/25/40G+ Nexus 9K Leaf
ACI-AD-XF	ACI Advantage SW license for a 10/25/40G+ Nexus 9K Leaf
NXOS-ES-XF	NX-OS Essential SW license for a 10/25/40G+ Nexus 9K Leaf
NXOS-AD-XF	NX-OS Advantage SW license for a 10/25/40G+ Nexus 9K Leaf
Ordering Information - Power Cords
CAB-250V-10A-AR	AC Power Cord - 250V, 10A - Argentina (2.5 meter)
CAB-250V-10A-BR	AC Power Cord - 250V, 10A - Brazil (2.1 meter)
CAB-250V-10A-CN	AC Power Cord - 250V, 10A - PRC (2.5 meter)
CAB-250V-10A-ID	AC Power Cord - 250V, 10A, South Africa (2.5 meter)
CAB-250V-10A-IS	AC Power Cord - 250V, 10A - Israel (2.5 meter)
CAB-9K10A-AU	Power Cord, 250VAC 10A 3112 Plug, Australia (2.5 meter)
CAB-9K10A-EU	Power Cord, 250VAC 10A CEE 7/7 Plug, EU (2.5 meter)
CAB-9K10A-IT	Power Cord, 250VAC 10A CEI 23-16/VII Plug, Italy (2.5 meter)
CAB-9K10A-SW	Power Cord, 250VAC 10A MP232 Plug, SWITZ (2.5 meter)
CAB-9K10A-UK	Power Cord, 250VAC 10A BS1363 Plug (13 A fuse), UK (2.5 meter)
CAB-9K12A-NA	Power Cord, 125VAC 13A NEMA 5-15 Plug, North America (2.5 meter)
CAB-AC-L620-C13	North America, NEMA L6-20-C13 (2.0 meter)
CAB-C13-C14-2M	Power Cord Jumper, C13-C14 Connectors, 2 Meter Length (2 meter)
CAB-C13-CBN	Cabinet Jumper Power Cord, 250 VAC 10A, C14-C13 Connectors (0.7 meter)
CAB-IND-10A	10A Power cable for India (2.5 meter)
CAB-N5K6A-NA	Power Cord, 200/240V 6A North America (2.5 meter)
CAB-HVAC-SD-0.6M	HVAC Power cable for Anderson-LS-25
CAB-HVAC-RT-0.6M	HVAC Power cable with right angle connector for RF-LS-25
Ordering Information - Accessories
NXK-ACC-KIT-1RU	Nexus Fixed Accessory Kit with 4-post rack mount kit

Reviews

11/13/2024

The product is firmly packed.

David

Verified Buyer

9/25/2023

Good service.

Patrick

Verified Buyer

Warranty

Standard Warranty Policy

All hardware sold by ITMall includes our 3-Year Free Maintenance and 1-Year RMA Replacement Service. Please refer to our Warranty Policy for details.

1-Year Advance Replacement (RMA)
3-Year Free Repair Service
Full coverage for functionality defects

Hassle-Free RMA Process

We streamlined the return process to minimize your network downtime. Our engineering team provides pre-return diagnostics to ensure hardware is truly defective.

30-Day satisfaction guarantee return window
Automated RMA portal access for instant tracking
Restocking fee waived for functionality issues

Certified Engineering Support

Our products are backed by CCIE-certified engineers who provide expert guidance on compatibility, configuration, and troubleshooting at no extra cost.

Free pre-sales topology consultation
Remote troubleshooting & firmware advice
Simulation lab testing before dispatch

Global Logistics & Packaging

We ship to 85+ countries using premium anti-static packaging to ensure safety. Orders placed before 14:00 (GMT+8) are typically dispatched the same day.

Double-walled boxes with customer molded foam
Blind shipping support for channel partners
Real-time tracking via FedEx / DHL / UPS

Resources

Datasheet

FAQ

What are the port configurations on the Cisco Nexus 93180YC-EX?

48 x 1/10/25-Gbps fiber ports and 6 x 40/100-Gbps QSFP28 ports, with flexible speed options for migration.

What is the performance of the Nexus 93180YC-EX?

3.6 Tbps bandwidth, over 2.6 bpps, less than 1 microsecond latency, 40 MB buffer.

Does it support Cisco ACI and NX-OS?

Yes, operates in both NX-OS mode for standard environments and ACI mode for policy-based automation.

What power options are available?

Up to 2 hot-swappable PSUs: 500W/650W AC, 930W DC, 1200W HVAC/HVDC; typical 210W, max 470W.

Is the product in stock and what's the pricing?

2 units in stock for immediate dispatch. Special offer: $13,500 (save 10%). PDF Datasheet available.

Is this product Brand New?

Yes, unless clearly marked as "Refurbished", all our products are Factory Sealed (Original New) sourced directly from authorized channels.

What is the warranty period?

We provide a comprehensive 3-Year Warranty on this item. This covers hardware defects and includes advanced replacement.

Do you offer volume discounts?

Yes! For bulk orders or project bids, please click "Quote | Help" to get a custom price proposal from our sales team.

How fast can you ship?

In-stock items ordered before 3 PM EST ship the same day. We offer overnight and 2-day shipping options via FedEx/DHL.
