SPECIFICATIONS
Performance
Enterprise Test Conditions
Threat Prevention1 (Gbps) 24
NGFW2 (Gbps) 40.5
IPS (Gbps) 43
Firewall (Gbps) 106.2
RFC 3511, 2544, 2647, 1242 Performance (Lab)
Firewall 1518B UDP (Gbps) 316.5
VPN AES-128 (Gbps) 40.1
Connections/sec 550000
Concurrent connections 10/20/32M
Additional Features
Highlights
- 2x CPUs,36 physical cores, 72 virtual cores
- 1x 1TB HDD or 480GB SSD, (2x SSD in Plus)
- 3x AC power supply
- 48,96 and 128 GB memory options
- Lights-Out-Management card (optional in Base package)
- Virtual Systems (base/PLUS/max mem): 125/250/250
Network Expansion Slot Options (7 of 8 slots open)
• 8x 10/100/1000Base-T RJ45 port card, up to 66 ports
• 4x 1000Base-F SFP port card, up to 32 ports
• 4x 10GBase-F SFP+ port card, up to 32 ports
• 2x 100/40/25G QSFP28 port double-slot-width card, up to 8 ports
Content Security
First Time Prevention Capabilities
• CPU-level, OS-level and static file analysis
• File disarm and reconstruction via Threat Extraction
• Average emulation time for unknown files that require full sandbox evaluation is under 100 seconds
• Maximal file size for Emulation is 100 MB
• Emulation OS Support: Windows XP, 7, 8.1, 10
Applications
• Use 10,000+ pre-defined or customize your own applications
• Accept, prevent, schedule, and apply traffic-shaping
Data Loss Prevention
• Classify 700+ pre-defined data types
• End user and data owner incident handling
Content Security (continued)
Dynamic User-based Policy
• Integrates with Microsoft AD, LDAP, RADIUS, Cisco pxGrid,
Terminal Servers and with 3rd parties via a Web API
• Enforce consistent policy for local and remote users on Windows,
macOS, Linux, Android and Apple iOS platforms
Network
Network Connectivity
• Integrated SD-WAN network optimization and resilience
• Total physical and virtual (VLAN) interfaces per appliance:
1024/4096 (single gateway/with virtual systems)
• 802.3ad passive and active link aggregation
• Layer 2 (transparent) and Layer 3 (routing) mode
High Availability
• Active/Active L2, Active/Passive L2 and L3
• Session failover for routing change, device and link failure
• ClusterXL or VRRP
IPv6
• NAT66, NAT64, NAT46
• CoreXL, SecureXL, HA with VRRPv3
Unicast and Multicast Routing (see SK98226)
• OSPFv2 and v3, BGP, RIP
• Static routes, Multicast routes
• Policy-based routing
• PIM-SM, PIM-SSM, PIM-DM, IGMP v2, and v3
Physical
Power Requirements
• Single Power Supply rating AC: 850W, DC: 1300W
• Power input: 100 to 240V (47-63Hz), 40~-72VDC
• Power consumption avg/max: 330/589W
• Maximum thermal output AC: 2009.8 BTU/hr.
Dimensions
• Enclosure: 3RU
• Dimensions (WxDxH): 17.4 x 24 x 5.2 in.(442x610x132mm)
• Weight : 46.3lbs. (21kg)
Environmental Conditions
• Operating: 0° to 40°C, humidity 5 to 95%
• Storage: –20° to 70°C, humidity 5 to 95%
Certifications
• Safety: UL, CB, CE, TUV GS
• Emissions: FCC, CE, VCCI, RCM/C-Tick
• Environmental: RoHS, WEEE, REACH1, ISO14001
