Offices, hotels, retail stores, factories, and schools
Highlight Features
-
2.5GE uplinks, overcoming GE limitations, supporting diverse access types, and enabling integration into 10GE networks
- Unique CPU protection policy, ensuring stability of the switch and nonstop services
- RLDP used to provide smooth network connections
- 10 kV surge protection for ports and high reliability
- Compliance with standard protocols and application in various scenarios
- Ease of use through Ruijie Cloud for management and remote O&M
Hardware Specifications
| Hardware Specifications | RG-S2915-48GT4MS-L | RG-S2915-24GT4MS-L | RG-S2915-24GT4MS-P-L | RG-S2915-10GT2MS-P-L |
| Interface Specifications | ||||
| Fixed Service Ports | 48 × 10/100/1000Base-T Ethernet ports with auto-negotiation, 4 × 2.5GE/1GE SFP ports | 24 × 10/100/1000Base-T Ethernet ports with auto-negotiation, 4 × 2.5GE/1GE SFP ports | 24 ×
10/100/1000Base-T Ethernet ports with auto-negotiation, 4 × 2.5G/1GE SFP ports |
10 × 10/100/1000Base-T Ethernet ports with auto-negotiation,
2 × 2.5GE/1GE SFP ports |
| Power modules | 1 fixed power module | 1 fixed power module | 1 fixed power module | 1 fixed power module |
| Fans modules | 2 fixed fans | 0 | 2 fixed fans | 1 fixed fans |
| Fixed management ports | 1 × RJ45 Console, 1 × USB port | 1 × RJ45 Console, 1 × USB port | 1 × RJ45 Console, 1 × USB port | 1 × RJ45 Console, 1 × USB port |
| System Specifications | ||||
| Packet forwarding rate | 87 Mpps | 51 Mpps | 51 Mpps | 22.5 Mpps |
| Switching capacity | 116Gbps | 68Gbps | 68Gbps | 30Gbps |
| MAC Table Capacity | 16,000 | 16,000 | 16,000 | 16,000 |
| ARP table | 512 | |||
| Routing Table Size (IPv4/IPv6) | 64 | |||
| ACL entries | 500 | |||
| Dimensions and Weight | ||||
| Dimensions (W x D x H) | 440 mm × 220 mm × 43.5 mm (17.32 in × 8.66 in × 1.71 in), 1 RU | 440 mm × 220 mm × 43.5 mm (17.32 in × 8.66 in × 1.71 in), 1 RU | 440 mm × 292 mm × 43.6 mm (17.32 in × 11.50 in × 1.72 in), 1 RU | 297 mm × 170 mm × 44.5 mm (11.69 in × 6.69 in × 1.75 in), 1 RU |
| Weight | 2.8 kg (6.17 lbs) | 2.5 kg (5.51 lbs) | 2.8 kg (6.17 lbs) | 2.5 kg (5.51 lbs) |
| CPU and Storage | ||||
| CPU | Built-in CPU, single-core processor, with the clock speed of 1.2 GHz | |||
| Flash Memory | 64 MB | |||
| SDRAM | 512 MB | |||
| Data packet buffer | 512 KB | |||
| Power and Consumption | ||||
| Maximum power consumption | < 30 W | < 15.6 W | < 33 W (non-PoE)
< 403 W (PoE full load) |
< 16 W (non-PoE)
< 141 W (PoE full load) |
| Rated input voltage | 100 V AC to 240 V AC, 50 Hz to 60 Hz | 100 V AC to 240 V AC, 50 Hz to 60 Hz | 100 V AC to 240 V AC, 50 Hz to 60 Hz | 100 V AC to 240 V AC, 50 Hz to 60 Hz |
| Maximum input voltage | 90 V AC to 264 V AC, 50 Hz to 60 Hz | 90 V AC to 264 V AC, 50 Hz to 60 Hz | 90 V AC to 264 V AC, 50 Hz to 60 Hz | 90 V AC to 264 V AC, 50 Hz to 60 Hz |
| Environment and Reliability | ||||
| MTBF | >200K | >200K | >200K | >200K |
| Operating Temperature | 0°C to 45°C (32°F to 113°F) | |||
| Storage Temperature | -40°C to +70°C (-40°F to +158°F) | |||
| Operating Humidity | 10% to 90% RH (non-condensing) | |||
| Storage Humidity | 5% to 95% RH (non-condensing) | |||
| Operating noise | ≤ 37 dB | Fanless | ≤ 39 dB | ≤ 37 dB |
| Interface surge protection | Power port: 6 kV/2 kV
Telecom port: 10 kV |
Power port: 6 kV/2 kV
Telecom port: 10 kV |
Power port: 6 kV/2 kV
Telecom port: 10 kV |
Power port: 6 kV/2 kV
Telecom port: 10 kV |
Software Specifications
| Feature | Description | |
| Ethernet switching | Jumbo frame (maximum length: 9216 bytes) | |
| 802.3az EEE | ||
| IEEE 802.1Q (4,094 VLANs) | ||
| Voice VLAN | ||
| Port based VLAN | ||
| Basic QinQ
Selective QinQ |
||
| STP (IEEE 802.1.d), RSTP (IEEE 802.1w), MSTP (IEEE 802.1s) | ||
| ERPS (G.8032) | ||
| LLDP/LLDP-MED | ||
| LACP (IEEE 802.3ad) | ||
| IP service | ARP | |
| DHCP client, DHCP relay, and DHCP server | ||
| DHCP snooping | ||
| DNS | ||
| IP routing | Static routing | |
| RIP, RIPng | ||
| OSPFv2 | ||
| ACL and QoS | Standard IP ACLs
Extended IP ACLs Extended MAC ACLs Expert-level ACLs ACL 80 IPv6 ACL |
|
| ACL redirection | ||
| Port traffic rate limiting | ||
| 802.1p, DSCP, IP precedence traffic prioritization (IEEE 802.1p) for real-time classification | ||
| Congestion management: RR, SP, WRR, DRR, WFQ, SP+WRR, SP+DRR, and SP+WFQ | ||
| Congestion avoidance: tail drop | ||
| Eight priority queues per interface | ||
| Security | RADIUS and TACACS+ | |
| Port-based and MAC-based 802.1x authentication | ||
| Web authentication | ||
| HTTPS | ||
| SSHv1, SSHv2 | ||
| IGMP V1,V2 snooping | ||
| IP Source Guard | ||
| CPP and NFPP | ||
| Reliability | RLDP | |
| Hot swapping of power modules and cables | ||
| Temperature Monitoring
Temperature Alarm Overtemperature Protection |
||
| NMS and maintenance | RSPAN | |
| sFlow | ||
| NTP | ||
| TFTP client | ||
| SNMP v1/v2c/v3 | ||
| CLI (telnet/console), syslog/debug, Web, MACC public cloud | ||
| CWMP (TR-069) standard protocol | ||
| gRPC | ||
| PoE | IEEE 802.3af and 802.3at
Uninterruptible power supply upon hot start Port priority |
|
Order Information
| Model | Description |
| RG-S2915-48GT4MS-L | 48 × 10/100/1000Base-T copper ports with auto-negotiation, 4 × 1GE/2.5GE SFP ports, fixed single AC power supply |
| RG-S2915-24GT4MS-L | 24 × 10/100/1000Base-T copper ports with auto-negotiation, 4 × 1GE/2.5GE SFP ports, fixed single AC power supply |
| RG-S2915-24GT4MS-P-L | 24 × 10/100/1000Base-T copper ports with auto-negotiation, 4 × 1GE/2.5GE SFP ports, fixed single AC power supply, PoE/PoE+ power supply, 370 W PoE power supply |
| RG-S2915-10GT2MS-P-L | 10 × 10/100/1000Base-T copper ports with auto-negotiation, 2 × 1GE/2.5GE SFP ports, fixed single AC power supply, PoE/PoE+ power supply, 125 W PoE power supply |
| 2.5G-SFP-LX03-SM1310-BIDI-I | SFP 2.5G BIDI transceiver-TX1310/RX1550, 3 km, LC |
| 2.5G-SFP-LX03-SM1550-BIDI-I | SFP 2.5G BIDI transceiver-TX1550/RX1310, 3 km, LC |
| MINI-GBIC-SX-MM850 | 1000BASE-SX, SFP transceiver, SM (850 nm, 500 m, LC). |
| MINI-GBIC-LX-SM1310 | 1000BASE-LX, SFP transceiver, SM (1310 nm, 10 km, LC) |
| MINI-GBIC-LH40-SM1310 | 1000BASE-LH, SFP transceiver, SM (1310 nm, 40 km, LC) |
| MINI-GBIC-ZX80-SM1550 | 1000BASE-ZX80, SFP transceiver, SM (1550 nm, 80 km, LC) |
| GE-SFP-LX20-SM1310-BIDI | SFP BIDI Transceiver-TX1310/RX1550, 20 km, LC |
| GE-SFP-LX20-SM1550-BIDI | SFP BIDI Transceiver-TX1550/RX1310, 20 km, LC |
| GE-SFP-LH40-SM1310-BIDI | SFP BIDI Transceiver-TX1310/RX1550, 40 km, LC |
| GE-SFP-LH40-SM1550-BIDI | SFP BIDI Transceiver-TX1550/RX1310, 40 km, LC |
| Mini-GBIC-GT | 1000BASE-TX, SFP transceiver (100 m) |
